generate_test_coordinate (complex)

Chapter 12: Utilities

generate_test_coordinate (complex)

Generates test matrices of class D(n, c) and E(n, c). Returns in either coordinate or band storage format, where possible.

Synopsis

#include <imsl.h>

void *imsl_c_generate_test_coordinate (int n, int c, int *nz, ..., 0)

The function is imsl_z_generate_test_coordinate is the double precision analogue.

Required Arguments

int n (Input)
Number of rows in the matrix.

int c (Input)
Parameter used to alter structure.

int *nz (Output)
Length of the return vector.

Return Value

A pointer to a vector of length nz of type imsl_c_sparse_elem. To release this space, use free. If no test was generated, then NULL is returned.

Synopsis with Optional Arguments

#include <imsl.h>

void *imsl_c_generate_test_coordinate (int n, int c, int *nz,
IMSL_D_MATRIX,
IMSL_SYMMETRIC_STORAGE,
0)

Optional Arguments

IMSL_D_MATRIX
Return a matrix of class D(n, c).
Default: Return a matrix of class E(n, c).

IMSL_SYMMETRIC_STORAGE,
For coordinate representation, return only values for the diagonal and lower triangle. This option is not allowed if IMSL_D_MATRIX is specified.

Description

The same nomenclature as Østerby and Zlatev (1982) is used. Test matrices of class E(n, c), to which we will generally refer to as E-matrices, are symmetric, positive definite matrices of order n with (6.0, 0.0) in the diagonal, (-1.0, 1.0) in the superdiagonal and (-1.0, -1.0) subdiagonal. In addition there are two bands at a distance c from the diagonal with (-1.0, 1.0) in the upper codiagonal and (-1.0, -1.0) in the lower codiagonal. More precisely:

ai,i = 6	0 £ i < n
ai,i+1 = -1 - i	0 £ i < n - 1
ai+1,1 = -1 - i	0 £ i < n - 1
ai,i+c = -1 + i	0 £ i < n - c
ai+c,i = -1 + i	0 £ i < n - c

for any n ³ 3 and 2 £ c £ n - 1.

Test matrices of class D(n, c) are square matrices of order n with a full diagonal, three bands at a distance c above the diagonal and reappearing cyclically under the diagonal, and a 10 ´ 10 triangle of elements in the upper-right corner. More precisely:

ai,i = 1	0 £ i < n
ai,i+c = i + 2	0 £ i < n - c
ai,i-n+c = i + 2	n - c £ i < n
ai,i+c+1 = -(i + 1)	0 £ i < n - c - 1
ai,i+c+1 = -(i + 1)	n - c - 1£ i < n
ai,i+c+2 = 16	0 £ i < n - c - 2
ai,i-n+c+2 = 16	n - c - 2£ i < n
ai,n-11+i+j = 100j	1 £ i< 11 - j, 0 £ j < 10

for any n ³ 14 and 1 £ c £ n - 13.

The sparsity pattern of D(20, 5) is as follows:

By default imsl_c_generate_test_coordinate returns an E-matrix in coordinate representation. By specifying the IMSL_SYMMETRIC_STORAGE option, only the diagonal and lower triangle are returned. The scalar nz will contain the number of non-zeros in this representation.

The option IMSL_D_MATRIX will return a matrix of class D(n, c). Since D-matrices are not symmetric, the IMSL_SYMMETRIC_STORAGE option is not allowed.

Examples

Example 1

This example generates the matrix

and prints the result.

#include "imsl.h"

main()

{

int i;

int n = 5;

int c = 3;

int nz;

Imsl_c_sparse_elem *a;

a = imsl_c_generate_test_coordinate (n, c, &nz, 0);

printf ("row col val\n");

for (i=0; i<nz; i++)

printf (" %d %d (%5.1f, %5.1f)\n",

a[i].row, a[i].col, a[i].val.re, a[i].val.im);

}

Output

row col val

0 0 ( 6.0, 0.0)

1 1 ( 6.0, 0.0)

2 2 ( 6.0, 0.0)

3 3 ( 6.0, 0.0)

4 4 ( 6.0, 0.0)

1 0 ( -1.0, -1.0)

2 1 ( -1.0, -1.0)

3 2 ( -1.0, -1.0)

4 3 ( -1.0, -1.0)

0 1 ( -1.0, 1.0)

1 2 ( -1.0, 1.0)

2 3 ( -1.0, 1.0)

3 4 ( -1.0, 1.0)

3 0 ( -1.0, -1.0)

4 1 ( -1.0, -1.0)

0 3 ( -1.0, 1.0)

1 4 ( -1.0, 1.0)

Example 2

In this example, the matrix E(5, 3) is returned in symmetric storage and printed.

#include <imsl.h>
