.p>.CMCH8.DOC!MIN_CON_GEN_LIN;min_con_gen_lin
Minimizes a general objective function subject to linear equality/inequality constraints.
Synopsis
#include <imsl.h>
float *imsl_f_min_con_gen_lin (void fcn(), int nvar, int ncon, int neq, float a[], float b[], float xlb[], float xub[], ..., 0)
The type double function is imsl_d_min_con_gen_lin.
Required Arguments
void fcn (int n, float x[], float *f )
(Input/Output)
User-supplied function to evaluate the function to be
minimized. Argument x is a vector of
length n at
which point the function is evaluated, and f contains the
function value at x.
int nvar
(Input)
Number of variables.
int ncon
(Input)
Number of linear constraints (excluding simple bounds).
int neq
(Input)
Number of linear equality constraints.
float a[]
(Input)
Array of size ncon ´ nvar containing the
equality constraint gradients in the first neq rows followed by
the inequality constraint gradients.
float b[]
(Input)
Array of size ncon containing the
right-hand sides of the linear constraints. Specifically, the constraints on the
variables
xi, i = 0, nvar - 1, are ak,0x0 + ¼ + ak,nvar-1xnvar-1 = bk, k = 0,
¼,
neq - 1 and ak,0x0 + ¼ + ak,nvar-1xnvar-1 £ bk, k = neq, ¼, ncon - 1. Note that the data that define the
equality constraints come before the data of the inequalities.
float xlb[]
(Input)
Array of length nvar containing the
lower bounds on the variables; choose a very large negative value if a component
should be unbounded below or set xub[i] = xub[i] to
freeze the i-th variable. Specifically, these simple bounds are xlb[i] £ xi, for i = 1, ¼, nvar.
float xub[]
(Input)
Array of length nvar containing the
upper bounds on the variables; choose a very large positive value if a component
should be unbounded above. Specifically, these simple bounds are xi £ xub[i], for
i = 1, nvar.
Return Value
A pointer to the solution x. To release this space, use free. If no solution can be computed, then NULL is returned.
Synopsis with Optional Arguments
#include <imsl.h>
float
*imsl_f_min_con_gen_lin (void fcn(), int nvar, int ncon,
int a, float b, float xlb[], float
xub[],
IMSL_XGUESS, float xguess[],
IMSL_GRADIENT, void
gradient(),
IMSL_MAX_FCN, int
max_fcn,
IMSL_NUMBER_ACTIVE_CONSTRAINTS, int
*nact,
IMSL_ACTIVE_CONSTRAINT, int
**iact,
IMSL_ACTIVE_CONSTRAINT_USER, int
*iact_user,
IMSL_LAGRANGE_MULTIPLIERS, float
**lagrange,
IMSL_LAGRANGE_MULTIPLIERS_USER, float
*lagrange_user,
IMSL_TOLERANCE, float tolerance,
IMSL_OBJ,
float *obj,
IMSL_RETURN_USER, float x[],
IMSL_FCN_W_DATA,
void fcn(), void *data,
IMSL_GRADIENT_W_DATA, void
grad(), void *data,
0)
Optional Arguments
IMSL_XGUESS, float xguess[]
(Input)
Array with n components
containing an initial guess.
Default: xguess = 0
IMSL_GRADIENT, void gradient
(int
n,
float
x[],
float
g[]) (Input)
User-supplied function to compute the
gradient at the point x, where x is a vector of
length n, and
g is the vector
of length n
containing the values of the gradient of the objective function.
IMSL_MAX_FCN, int max_fcn
(Input)
Maximum number of function evaluations.
Default: max_fcn = 400
IMSL_NUMBER_ACTIVE_CONSTRAINTS, int *nact
(Output)
Final number of active constraints.
IMSL_ACTIVE_CONSTRAINT, int **iact
(Output)
The address of a pointer to an int, which on exit, points to
an array containing the nact indices of the
final active constraints.
IMSL_ACTIVE_CONSTRAINT_USER, int
*iact_user (Output)
A user-supplied array of length at
least ncon +
2*nvar
containing the indices of the final active constraints in the first nact locations.
IMSL_LAGRANGE_MULTIPLIERS, float
**lagrange (Output)
The address of a pointer, which on
exit, points to an array containing the Lagrange multiplier estimates of
the final active constraints in the first nact locations.
IMSL_LAGRANGE_MULTIPLIERS_USER, float
*lagrange_user (Output)
A user-supplied array of length at
least nvar
containing the Lagrange multiplier estimates of the final active constraints in
the first nact
locations.
IMSL_TOLERANCE, float tolerance
(Input)
The nonnegative tolerance on the first order conditions at the
calculated solution.
Default: tolerance =
, where e is machine epsilon
IMSL_OBJ, float *obj
(Output)
The value of the objective function.
IMSL_RETURN_USER, float x[]
(Output)
User-supplied array with nvar components
containing the computed solution.
IMSL_FCN_W_DATA, void fcn (int n, float x[], float *f , void *data),
void
*data (Input)
User supplied function to compute the value of the
function to be minimized, which also accepts a pointer to data that is supplied
by the user. data is a pointer to
the data to be passed to the user-supplied function. See the Introduction, Passing Data to
User-Supplied Functions at the beginning of this manual for more
details.
IMSL_GRADIENT_W_DATA, void gradient
(int
n,
float
x[],
float
g[],void
*data) , void *data
(Input)
User-supplied function to compute the gradient at the point x, which also accepts
a pointer to data that is supplied by the user. data is a pointer to
the data to be passed to the user-supplied function. See the Introduction, Passing Data to
User-Supplied Functions at the beginning of this manual for more
details.
Description
The function imsl_f_min_con_gen_lin is based on M.J.D. Powell’s TOLMIN, which solves linearly constrained optimization problems, i.e., problems of the form
min f (x)
subject to
given the vectors b1, b2, xl ,and xu and the matrices A1 and A2.
The algorithm starts by checking the equality constraints for inconsistency and redundancy. If the equality constraints are consistent, the method will revise x0, the initial guess, to satisfy
Next, x0 is adjusted to satisfy the simple bounds and inequality constraints. This is done by solving a sequence of quadratic programming subproblems to minimize the sum of the constraint or bound violations.
Now, for each iteration with a feasible xk, let Jk be the set of indices of inequality constraints that have small residuals. Here, the simple bounds are treated as inequality constraints. Let Ik be the set of indices of active constraints. The following quadratic programming problem
subject to
is solved to get (dk, lk) where aj is a row vector
representing either a constraint in
A1 or A2 or a bound constraint on
x. In the latter case, the aj = ei for the bound
constraint xi £ (xu)i and aj = -ei for the constraint
-xi £ (xl)i. Here, ei is a vector with 1 as
the i-th component, and zeros elsewhere. Variables lk are the Lagrange
multipliers, and Bk is a positive definite
approximation to the second derivative Ñ2 f(xk).
After the search direction dk is obtained, a line search is performed to locate a better point. The new point xk+1 = xk +akdk has to satisfy the conditions
and
The main idea in forming the set Jk is that, if any of the equality constraints restricts the step-length ak, then its index is not in Jk. Therefore, small steps are likely to be avoided.
Finally, the second derivative approximation BK, is updated by the BFGS formula, if the condition
holds. Let xk ¬ xk+1, and start another iteration.
The iteration repeats until the stopping criterion
is satisfied. Here t is the supplied tolerance. For more details, see Powell (1988, 1989).
Since a finite difference method is used to approximate the gradient for some single precision calculations, an inaccurate estimate of the gradient may cause the algorithm to terminate at a noncritical point. In such cases, high precision arithmetic is recommended. Also, if the gradient can be easily provided, the option IMSL_GRADIENT should be used.
Example 1
In this example, the problem
is solved.
#include "imsl.h"
main()
{
void fcn(int, float *, float *);
int neq = 2;
int ncon = 2;
int nvar = 5;
float a[] = {1.0,
1.0, 1.0, 1.0, 1.0,
0.0, 0.0, 1.0, -2.0, -2.0};
float b[] = {5.0, -3.0};
float xlb[] = {0.0, 0.0, 0.0, 0.0, 0.0};
float xub[] = {10.0, 10.0, 10.0, 10.0, 10.0};
float *x;
x =
imsl_f_min_con_gen_lin(fcn, nvar, ncon, neq, a, b, xlb, xub,
0);
imsl_f_write_matrix("Solution", 1, nvar, x, 0);
}
void fcn(int n, float *x, float *f)
{
*f = x[0]*x[0] + x[1]*x[1] + x[2]*x[2] + x[3]*x[3] + x[4]*x[4]
- 2.0*x[1]*x[2] - 2.0*x[3] * x[4] - 2.0*x[0];
}
Output
Solution
1 2 3 4 5
1 1 1 1 1
Example 2
In this example, the problem from Schittkowski (1987)
is solved with an initial guess of x0 = 10, x1 = 10 and x2 = 10.
#include "imsl.h"
main()
{
void fcn(int, float *, float *);
void grad(int, float *, float *);
int neq = 0;
int ncon = 2;
int nvar = 3;
int lda = 2;
float obj, x[3];
float a[] = {-1.0, -2.0, -2.0,
1.0, 2.0, 2.0};
float xlb[] = {0.0, 0.0, 0.0};
float xub[] = {20.0, 11.0, 42.0};
float xguess[] = {10.0, 10.0, 10.0};
float b[] = {0.0, 72.0};
imsl_f_min_con_gen_lin(fcn, nvar, ncon, neq, a, b, xlb, xub,
IMSL_GRADIENT, grad,
IMSL_XGUESS, xguess,
IMSL_OBJ, &obj,
IMSL_RETURN_USER, x,
0);
imsl_f_write_matrix("Solution", 1, nvar, x,
0);
printf("Objective value = %f\n", obj);
}
void fcn(int n, float *x, float *f)
{
*f = -x[0] * x[1] * x[2];
}
void grad(int n, float *x, float *g)
{
g[0] = -x[1]*x[2];
g[1] = -x[0]*x[2];
g[2] = -x[0]*x[1];
}
Output
Solution
1 2 3
20 11 15
Objective value = -3300.000000
|
