Solves a system of partial differential equations of the form ut = f(x, t, u, ux, uxx) using the method of lines. The solution is represented with cubic Hermite polynomials.
Synopsis
#include <imsl.h>
void imsl_f_pde_method_of_lines_mgr (int task, void **state, ..., 0)
void
imsl_f_pde_method_of_lines (int
npdes, float
*t,
float tend, int
nx,
float
xbreak[], float
y[], void *state, void fcn_ut(),
void fcn_bc())
The type double functions are imsl_d_pde_method_of_lines_mgr and imsl_d_pde_method_of_lines.
Required Arguments for imsl_f_pde_method_of_lines_mgr
int task
(Input)
This function must be called with task set to IMSL_PDE_INITIALIZE to
set up memory and default values prior to solving a problem and with task equal
to IMSL_PDE_RESET to
clean up after it has solved. These values for task are defined in the header
file imsl.h.
void **state
(Input/Output)
The current state of the PDE solution is held in a structure
pointed to by state. It cannot be
directly manipulated.
Required Arguments for imsl_f_pde_method_of_lines
int npdes
(Input)
Number of differential equations.
float *t
(Input/Output)
Independent variable. On input, t supplies the initial
time, t0. On output, t is set to the value
to which the integration has been updated. Normally, this new value is tend.
float tend
(Input)
Value of t = tend at which the
solution is desired.
int nx
(Input)
Number of mesh points or lines.
float xbreak[]
(Input)
Array of length nx containing the
breakpoints for the cubic Hermite splines used in the x discretization.
The points in xbreak must be
strictly increasing. The values xbreak[0] and xbreak[nx - 1] are the endpoints of the interval.
float y[]
(Input/Output)
Array of size npdes by nx containing the
solution. The array y contains the
solution as y[k,i] = uk(x, tend) at x =
xbreak[i]. On input, y
contains the initial values. It must satisfy the boundary conditions. On output,
y contains the
computed solution.
void *state
(Input/Output)
The current state of the PDE solution is held in a structure
pointed to by state. It must be initialized by a call to imsl_f_pde_method_of_lines_mgr.
It cannot be directly manipulated.
void
fcn_ut(int npdes, float x, float t, float u[], float ux[], float uxx[], float
ut[])
User-supplied function to evaluate ut.
int npdes
(Input)
Number of equations.
float x
(Input)
Space variable, x.
float t
(Input)
Time variable, t.
float u[]
(Input)
Array of length npdes containing the
dependent values, u.
float ux[]
(Input)
Array of length npdes containing the
first derivatives, ux.
float uxx[]
(Input)
Array of length npdes containing the
second derivative, uxx.
float ut[]
(Output)
Array of length npdes containing the
computed derivatives ut.
void
fcn_bc(int npdes, float x, float t, float alpha[], float beta[],
float
gammap[])
User-supplied function to evaluate the boundary conditions.
The boundary conditions accepted by imsl_f_pde_method_of_lines
are
Note: Users must supply the values ak and bk, which determine the values gk. Since gk can depend on t values of gk¢ also are required.
int npdes
(Input)
Number of equations.
float x
(Input)
Space variable, x.
float t
(Input)
Time variable, t.
float alpha[]
(Output)
Array of length npdes containing the
ak values.
float beta[]
(Output)
Array of length npdes containing the
bk values.
float gammap[]
(Output)
Array of length npdes containing the
derivatives,
Synopsis with Optional Arguments
#include <imsl.h>
void
imsl_f_pde_method_of_lines_mgr (int task, void
**state,
IMSL_TOL, float tol,
IMSL_HINIT, float
hinit,
IMSL_INITIAL_VALUE_DERIVATIVE, float
initial_deriv[],
IMSL_HTRIAL, float *htrial,
IMSL_FCN_UT_W_DATA,
void fcn_ut (), void *data,
IMSL_FCN_BC_W_DATA,
void fcn_bc (), void *data,
0)
Optional Arguments
IMSL_TOL, float tol
(Input)
Differential equation error tolerance. An attempt is made to control
the local error in such a way that the global relative error is proportional to
tol.
Default:
tol = 100.0*imsl_f_machine(4)
IMSL_HINIT, float hinit
(Input)
Initial step size in the t integration. This value must
be nonnegative. If hinit is zero, an
initial step size of 0.001|tend - t0| will be
arbitrarily used. The step will be applied in the direction of
integration.
Default: hinit = 0.0
IMSL_INITIAL_VALUE_DERIVATIVE, float
initial_deriv[] (Input/Output)
Supply the derivative
values ux(x, t0). This
derivative information is input as
The array initial_deriv contains the derivative values as output:
Default: Derivatives are computed using cubic
spline interpolation
IMSL_HTRIAL, float *htrial
(Output)
Return the current trial step size.
IMSL_UT_FCN_W_DATA, void
fcn_ut(int npdes, float x, float t, float u[], float ux[], float uxx[], float ut[], void *data),
void
*data (Input)
User-supplied function to evaluate ut, which also
accepts a pointer to data that is supplied by the user. data is a pointer to the
data to be passed to the user-supplied function. See the Introduction, Passing Data to
User-Supplied Functions at the beginning of this manual for more
details.
IMSL_BC_FCN_W_DATA, void
fcn_bc(int npdes, float x, float t,
float alpha[], float beta[], float gammap[], void *data),
void
*data (Input)
User-supplied function to evaluate the boundary
conditions, which also accepts a pointer to data that is supplied by the
user. data is a pointer to the data to be passed to the user-supplied
function. See the Introduction, Passing Data to
User-Supplied Functions at the beginning of this manual for more
details.
Description
Let M = npdes, N = nx and xi = xbreaK(I). The routine imsl_f_pde_method_of_lines uses the method of lines to solve the partial differential equation system
with the initial conditions
uk = uk(x, t) at t = t0
and the boundary conditions
for k = 1, ¼, M.
Cubic Hermite polynomials are used in the x variable approximation so that the trial solution is expanded in the series
where fi(x) and yi(x) are the standard basis functions for the cubic Hermite polynomials with the knots x1 < x2 < ¼ < xN. These are piecewise cubic polynomials with continuous first derivatives. At the breakpoints, they satisfy
According to the collocation method, the coefficients of the approximation are obtained so that the trial solution satisfies the differential equation at the two Gaussian points in each subinterval,
for j = 1, ¼, N. The collocation approximation to the differential equation is
for k = 1, ¼, M and j = 1, ¼, 2(N - 1).
This is a system of 2M(N - 1) ordinary differential equations in 2M N unknown coefficient functions, ai,k and bi,k. This system can be written in the matrix−vector form as A dc/dt = F (t, y) with c(t0) = c0 where c is a vector of coefficients of length 2M N and c0 holds the initial values of the coefficients. The last 2M equations are obtained by differentiating the boundary conditions
for k = 1, ¼, M.
The initial conditions uk(x,
t0) must satisfy the
boundary conditions. Also, the
gk(t) must be
continuous and have a smooth derivative, or the boundary conditions will not be
properly imposed for t > t0.
If ak = bk = 0, it is assumed that no boundary condition is desired for the k-th unknown at the left endpoint. A similar comment holds for the right endpoint. Thus, collocation is done at the endpoint. This is generally a useful feature for systems of first-order partial differential equations.
If the number of partial differential equations is M = 1 and the number of breakpoints is N = 4, then
The vector c is
c = [a1, b1, a2, b2, a3, b3, a4, b3]T
and the right-side F is
If M > 1, then each entry in the above matrix is replaced by an M ´ M diagonal matrix. The element a1 is replaced by diag(a1,1, ¼, a1,M). The elements aN, b1 and bN are handled in the same manner. The fi(pj) and yi(pj) elements are replaced by fi(pj)IM and yi(pj)IM where IM is the identity matrix of order M. See Madsen and Sincovec (1979) for further details about discretization errors and Jacobian matrix structure.
The input/output array Y contains the values of the ak,i. The initial values of the bk,i are obtained by using the IMSL cubic spline routine imsl_f_cub_spline_interp_e_cnd (Chapter 3, “Interpolation and Approximation”;;) to construct functions
such that
The IMSL routine imsl_f_cub_spline_value, Chapter 3, “Interpolation and Approximation;” is used to approximate the values
There is an optional use of imsl_f_pde_method_of_lines that allows the user to provide the initial values of bk,i.
The order of matrix A is 2M N and its maximum bandwidth is 6M - 1. The band structure of the Jacobian of F with respect to c is the same as the band structure of A. This system is solved using a modified version of imsl_f_ode_adams_gear. Some of the linear solvers were removed. Numerical Jacobians are used exclusively. The algorithm is unchanged. Gear’s BDF method is used as the default because the system is typically stiff.
Four examples of PDEs are now presented that illustrate how users can interface their problems with IMSL PDE solving software. The examples are small and not indicative of the complexities that most practitioners will face in their applications. A set of seven sample application problems, some of them with more than one equation, is given in Sincovec and Madsen (1975). Two further examples are given in Madsen and Sincovec (1979).
Examples
Example 1
The normalized linear diffusion PDE, ut = uxx, 0 £ x £ 1, t > t0, is solved. The
initial values are t0 = 0,
u(x, t0) = u0 = 1. There is a
“zero-flux” boundary condition at
x =
1, namely ux(1, t) = 0,
(t > t0). The boundary value
of u(0, t) is abruptly changed from u0 to the value
u1 = 0.1. This transition
is completed by t = tδ = 0.09.
Due to restrictions in the type of boundary conditions successfully processed by imsl_f_pde_method_of_lines, it is necessary to provide the derivative boundary value function g¢ at x = 0 and at x = 1. The function g at x = 0 makes a smooth transition from the value u0 at t = t0 to the value u1 at t = tδ. The transition phase for g¢ is computed by evaluating a cubic interpolating polynomial. For this purpose, the function subprogram imsl_f_cub_spline_value, Chapter 3;, “Interpolation and Approximation” is used. The interpolation is performed as a first step in the user-supplied routine fcn_bc. The function and derivative values g(t0) = u0, g¢(t0) = 0, g(tδ) = u1, and g¢(tδ) = 0, are used as input to routine imsl_f_cub_spline_interp_e_cnd, to obtain the coefficients evaluated by imsl_f_cub_spline_value. Notice that g¢(t) = 0, t > tδ. The evaluation routine imsl_f_cub_spline_value will not yield this value so logic in the routine fcn_bc assigns g¢(t) = 0, t > tδ.
#include <imsl.h>
#include <math.h>
main()
{
void fcnut(int, float, float, float *, float *, float *,
float *);
void fcnbc(int, float, float, float *, float *,
float *);
int npdes = 1;
int nx = 8;
int i;
int j = 1;
int nstep = 10;
float t = 0.0;
float tend;
float xbreak[8];
float y[8];
char title[50];
void *state;
/* Set breakpoints and initial conditions */
for (i = 0; i
< nx; i++) {
xbreak[i] = (float) i / (float) (nx - 1);
y[i] = 1.0;
}
/* Initialize the solver */
imsl_f_pde_method_of_lines_mgr(IMSL_PDE_INITIALIZE, &state,
0);
while (j <=
nstep) {
tend = (float) j++ / (float) nstep;
tend *= tend;
/* Solve the problem */
imsl_f_pde_method_of_lines(npdes, &t, tend, nx, xbreak, y,
state, fcnut, fcnbc);
/* Print results at current t=tend */
sprintf(title, "solution at t = %4.2f\0", t);
imsl_f_write_matrix(title, npdes, nx, y, 0);
}
}
void fcnut(int npdes, float x, float t, float *u, float
*ux, float *uxx,
float *ut)
{
/* Define the PDE */
*ut = *uxx;
}
void fcnbc(int npdes, float x, float t, float *alpha,
float *beta,
float *gamp)
{
static int ndata;
static int first = 1;
static float delta = 0.09;
static float u0 = 1.0;
static float u1 = 0.1;
static float dfdata[2];
static float xdata[2];
static float fdata[2];
static Imsl_f_ppoly *ppoly;
/* Compute interpolant first time only */
if (first)
{
first = 0;
ndata = 2;
xdata[0] = 0.0;
xdata[1] = delta;
fdata[0] = u0;
fdata[1] = u1;
dfdata[0] = dfdata[1] = 0.0;
ppoly = imsl_f_cub_spline_interp_e_cnd(ndata, xdata, fdata,
IMSL_LEFT, 1, dfdata[0],
IMSL_RIGHT, 1, dfdata[1],
0);
}
/* Define boundary conditions */
if (x == 0.0)
{
/* These are for x = 0 */
*alpha = 1.0;
*beta = 0.0;
*gamp = 0.0;
/* If in the boundary layer, compute
nonzero gamma prime */
if (t <= delta)
*gamp = imsl_f_cub_spline_value(t, ppoly,
IMSL_DERIV, 1,
0);
} else {
/* These are for x = 1 */
*alpha = 0.0;
*beta = 1.0;
*gamp = 0.0;
}
}
Output
solution at t = 0.01
1 2 3 4 5 6
0.969 0.997 1.000 1.000 1.000 1.000
7 8
1.000 1.000
solution at t = 0.04
1 2 3 4 5 6
0.625 0.871 0.962 0.991 0.998 1.000
7 8
1.000 1.000
solution at t = 0.09
1 2 3 4 5 6
0.1000 0.4602 0.7169 0.8671 0.9436 0.9781
7 8
0.9917 0.9951
solution at t = 0.16
1 2 3 4 5 6
0.1000 0.3130 0.5071 0.6681 0.7893 0.8708
7 8
0.9168 0.9315
solution at t = 0.25
1 2 3 4 5 6
0.1000 0.2567 0.4045 0.5354 0.6428 0.7224
7 8
0.7710 0.7874
solution at t = 0.36
1 2 3 4 5 6
0.1000 0.2176 0.3292 0.4292 0.5125 0.5751
7 8
0.6139 0.6270
solution at t = 0.49
1 2 3 4 5 6
0.1000 0.1852 0.2661 0.3386 0.3992 0.4448
7 8
0.4731 0.4827
solution at t = 0.64
1 2 3 4 5 6
0.1000 0.1588 0.2147 0.2648 0.3066 0.3381
7 8
0.3577 0.3643
solution at t = 0.81
1 2 3 4 5 6
0.1000 0.1387 0.1754 0.2083 0.2358 0.2565
7 8
0.2694 0.2738
solution at t = 1.00
1 2 3 4 5 6
0.1000 0.1242 0.1472 0.1678 0.1850 0.1980
7 8
0.2060 0.2087
Example 2
Here, Problem C is solved from Sincovec and Madsen (1975). The equation is of diffusion-convection type with discontinuous coefficients. This problem illustrates a simple method for programming the evaluation routine for the derivative, ut. Note that the weak discontinuities at x = 0.5 are not evaluated in the expression for ut. The problem is defined as
#include <imsl.h>
#include <math.h>
main()
{
void fcnut(int, float, float, float *, float *, float *,
float *);
void fcnbc(int, float, float, float *, float *,
float *);
int npdes = 1;
int nx = 100;
int i;
int j = 1;
int nstep = 10;
float t = 0.0;
float tend;
float xbreak[100];
float y[100];
float tol, hinit;
char title[50];
void *state;
/* Set breakpoints and initial conditions */
for (i = 0; i
< nx; i++) {
xbreak[i] = (float) i / (float) (nx - 1);
y[i] = 0.0;
}
y[0] = 1.0;
/* Initialize the solver */
tol =
sqrt(imsl_f_machine(4));
hinit = 0.01*tol;
imsl_f_pde_method_of_lines_mgr(IMSL_PDE_INITIALIZE, &state,
IMSL_TOL, tol,
IMSL_HINIT, hinit,
0);
while (j <=
nstep) {
tend = (float) j++ / (float) nstep;
/* Solve the problem */
imsl_f_pde_method_of_lines(npdes, &t, tend, nx, xbreak, y,
state, fcnut, fcnbc);
}
/* Print results at t=tend */
sprintf(title, "solution at t = %4.2f\0", t);
imsl_f_write_matrix(title, npdes, nx, y, 0);
}
void fcnut(int npdes, float x, float t, float *u, float
*ux, float *uxx,
float *ut)
{
/* Define the PDE */
float v;
float d;
if (x <=
0.5) {
d = 5.0;
v = 1000.0;
}
else
d = v = 1.0;
ut[0] =
d*uxx[0] - v*ux[0];
}
void fcnbc(int npdes, float x, float t, float *alpha,
float *beta,
float *gamp)
{
*alpha = 1.0;
*beta = 0.0;
*gamp = 0.0;
}
Output
solution at t = 1.00
1 2 3 4 5 6
1.000 1.000 1.000 1.000 1.000 1.000
7 8 9 10 11 12
1.000 1.000 1.000 1.000 1.000 1.000
13 14 15 16 17 18
1.000 1.000 1.000 1.000 1.000 1.000
19 20 21 22 23 24
1.000 1.000 1.000 1.000 1.000 1.000
25 26 27 28 29 30
1.000 1.000 1.000 1.000 1.000 1.000
31 32 33 34 35 36
1.000 1.000 1.000 1.000 1.000 1.000
37 38 39 40 41 42
1.000 1.000 1.000 1.000 1.000 1.000
43 44 45 46 47 48
1.000 1.000 1.000 1.000 1.000 1.000
49 50 51 52 53 54
1.000 0.997 0.984 0.969 0.953 0.937
55 56 57 58 59 60
0.921 0.905 0.888 0.872 0.855 0.838
61 62 63 64 65 66
0.821 0.804 0.786 0.769 0.751 0.733
67 68 69 70 71 72
0.715 0.696 0.678 0.659 0.640 0.621
73 74 75 76 77 78
0.602 0.582 0.563 0.543 0.523 0.502
79 80 81 82 83 84
0.482 0.461 0.440 0.419 0.398 0.376
85 86 87 88 89 90
0.354 0.332 0.310 0.288 0.265 0.242
91 92 93 94 95 96
0.219 0.196 0.172 0.148 0.124 0.100
97 98 99 100
0.075 0.050 0.025 0.000
Example 3
In this example, using imsl_f_pde_method_of_lines, the linear normalized diffusion PDE ut = uxx is solved but with an optional use that provides values of the derivatives, ux, of the initial data. Due to errors in the numerical derivatives computed by spline interpolation, more precise derivative values are required when the initial data is u(x, 0) = 1 + cos[(2n - 1)px], n > 1. The boundary conditions are “zero flux” conditions ux(0, t) = ux(1, t) = 0 for t > 0. Note that the initial data is compatible with these end conditions since the derivative function
vanishes at x = 0 and x = 1.
This optional usage signals that the derivative of the initial data is passed by the user. The values u(x, tend) and ux(x, tend) are output at the breakpoints with the optional usage.
#include <imsl.h>
#include <math.h>
main()
{
void fcnut(int, float, float, float *, float *, float *,
float *);
void fcnbc(int, float, float, float *, float *, float *);
int npdes = 1;
int nx = 10;
int i;
int j = 1;
int nstep = 10;
float t = 0.0;
float tend = 0.0;
float xbreak[10];
float y[10], deriv[10];
float tol, hinit;
float pi, arg;
char title1[50];
char title2[50];
void *state;
pi =
imsl_d_constant("pi", 0);
arg = 9.0 * pi;
/* Set breakpoints and initial conditions */
for (i = 0; i
< nx; i++) {
xbreak[i] = (float) i / (float) (nx - 1);
y[i] = 1.0 + cos(arg * xbreak[i]);
deriv[i] = -arg * sin(arg * xbreak[i]);
}
/* Initialize the solver */
tol =
sqrt(imsl_f_machine(4));
imsl_f_pde_method_of_lines_mgr(IMSL_PDE_INITIALIZE, &state,
IMSL_TOL, tol,
IMSL_INITIAL_VALUE_DERIVATIVE,
deriv,
0);
while (j <=
nstep) {
j++;
tend += 0.001;
/* Solve the problem */
imsl_f_pde_method_of_lines(npdes, &t, tend, nx, xbreak, y,
state, fcnut, fcnbc);
/* Print results at at every other t=tend */
if (j % 2) {
sprintf(title1, "\nsolution at t = %5.3f\0", t);
sprintf(title2, "\nderivative at t = %5.3f\0", t);
imsl_f_write_matrix(title1, npdes, nx, y, 0);
imsl_f_write_matrix(title2, npdes, nx, deriv, 0);
}
}
}
void fcnut(int npdes, float x, float t, float *u, float
*ux, float *uxx,
float *ut)
{
/* Define the PDE */
ut[0] =
uxx[0];
}
void fcnbc(int npdes, float x, float t, float *alpha,
float *beta,
float *gamp)
{
/* Define the boundary conditions */
alpha[0] =
0.0;
beta[0] = 1.0;
gamp[0] = 0.0;
}
Output
solution at t = 0.002
1 2 3 4 5 6
1.233 0.767 1.233 0.767 1.233 0.767
7 8 9 10
1.233 0.767 1.233 0.767
derivative at t = 0.002
1 2 3 4 5 6
0.000e+00 -5.172e-07 1.911e-06 1.818e-06 -5.230e-07 2.408e-06
7 8 9 10
-2.517e-06 3.194e-06 -3.608e-06 2.023e-06
solution at t = 0.004
1 2 3 4 5 6
1.053 0.947 1.053 0.947 1.053 0.947
7 8 9 10
1.053 0.947 1.053 0.947
derivative at t = 0.004
1 2 3 4 5 6
0.000e+00 -1.332e-06 -9.059e-06 -4.401e-06 5.006e-06 -2.134e-06
7 8 9 10
-1.733e-06 4.625e-06 6.741e-07 2.023e-06
solution at t = 0.006
1 2 3 4 5 6
1.012 0.988 1.012 0.988 1.012 0.988
7 8 9 10
1.012 0.988 1.012 0.988
derivative at t = 0.006
1 2 3 4 5 6
0.000e+00 -1.408e-06 -1.018e-06 -6.572e-07 -8.213e-07 -1.151e-06
7 8 9 10
1.051e-06 1.257e-06 -2.920e-07 2.023e-06
solution at t = 0.008
1 2 3 4 5 6
1.003 0.997 1.003 0.997 1.003 0.997
7 8 9 10
1.003 0.997 1.003 0.997
derivative at t = 0.008
1 2 3 4 5 6
0.000e+00 -1.028e-06 4.270e-06 3.114e-06 -3.085e-06 -1.492e-06
7 8 9 10
2.126e-06 -1.280e-06 -1.541e-06 2.023e-06
solution at t = 0.010
1 2 3 4 5 6
1.001 0.999 1.001 0.999 1.001 0.999
7 8 9 10
1.001 0.999 1.001 0.999
derivative at t = 0.010
1 2 3 4 5 6
0.000e+00 -7.596e-07 2.819e-07 1.547e-07 -1.469e-06 -9.516e-07
7 8 9 10
2.889e-07 8.956e-08 5.992e-07 2.023e-06
Example 4
In this example, consider the
linear normalized hyperbolic PDE, utt = uxx, the “vibrating
string” equation. This naturally leads to a system of first order PDEs. Define a
new dependent variable ut = v. Then,
vt = uxx is the second
equation in the system. Take as initial data u(x, 0) = sin(px) and ut(x, 0) =
v(x, 0) = 0. The ends of the string are fixed so
u(0, t) = u(1, t) =
v(0, t) = v(1, t) = 0. The exact solution
to this problem is
u(x,
t) = sin(px) cos(pt). Residuals are computed at the
output values of t for 0 < t £ 2. Output is obtained at 200 steps in
increments of 0.01.
Even though the sample code imsl_f_pde_method_of_lines gives satisfactory results for this PDE, users should be aware that for nonlinear problems, “shocks” can develop in the solution. The appearance of shocks may cause the code to fail in unpredictable ways. See Courant and Hilbert (1962), pp 488-490, for an introductory discussion of shocks in hyperbolic systems.
#include <imsl.h>
#include <math.h>
main()
{
void fcnut(int, float, float, float *, float *, float *,
float *);
void fcnbc(int, float, float, float *, float *, float *);
int npdes = 2;
int nx = 10;
int i;
int j = 1;
int nstep = 200;
float t = 0.0;
float tend = 0.0;
float xbreak[20];
float y[20], deriv[20];
float tol, hinit;
float pi;
float error[10], erru;
void *state;
pi = imsl_d_constant("pi",
0);
/* Set breakpoints and initial conditions */
for (i = 0; i < nx; i++)
{
xbreak[i] = (float) i / (float) (nx - 1);
y[i] = sin(pi * xbreak[i]);
y[nx + i] = 0.0;
deriv[i] = pi * cos(pi * xbreak[i]);
deriv[nx + i] = 0.0;
}
/* Initialize the solver */
tol =
sqrt(imsl_f_machine(4));
imsl_f_pde_method_of_lines_mgr(IMSL_PDE_INITIALIZE, &state,
IMSL_TOL, tol,
IMSL_INITIAL_VALUE_DERIVATIVE,
deriv,
0);
while (j <= nstep) {
j++;
tend += 0.01;
/* Solve the problem */
imsl_f_pde_method_of_lines(npdes, &t, tend, nx, xbreak, y,
state, fcnut, fcnbc);
/* Look at output at steps of 0.01
and compute errors */
for (i = 0; i < nx; i++) {
error[i] = y[i] - sin(pi * xbreak[i]) *
cos(pi *tend);
erru = imsl_f_max(erru, fabs(error[i]));
}
}
printf("Maximum error in u(x,t) = %e\n", erru);
}
void fcnut(int npdes, float x, float t, float *u, float
*ux, float *uxx,
float *ut)
{
/* Define the PDE */
ut[0] =
u[1];
ut[1] = uxx[0];
}
void fcnbc(int npdes, float x, float t, float *alpha,
float *beta,
float *gamp)
{
/* Define the boundary conditions */
alpha[0] =
1.0;
beta[0] = 0.0;
gamp[0] = 0.0;
alpha[1] = 1.0;
beta[1] = 0.0;
gamp[1] = 0.0;
}
Output
Maximum error in u(x,t) = 6.228203e-04
|
Visual Numerics, Inc. PHONE: 713.784.3131 FAX:713.781.9260 |
